Hybrid|Three Phase|Low voltage |
||||
| Model Name | D5K-TL | D8K-TL | D1OK-TL | D12K-TL |
| Off-grid Output | ||||
| Nominal Output Power | 5KW | 8KW | 10KW | 12KW |
| Max.Output Current | 15A | 24A | 30A | 30A |
| Peak Power&Duration | 16KW-10S | 20KW-10S | 20KW-10S | 20KW-10S |
| Nominal Output Voltage | 3/N/PE,220/380Vac,230/400Vac | |||
| Generator Port | Support | |||
| On-grid Parameter | ||||
| Nominal Output Power | 5KW | 8KW | 10KW | 12KW |
| Max.Output Power | 6KW | 9.6KW | 12KW | 14.4KW |
| Max.Input Power from Grid | 10KW | 16KW | 20KW | 24KW |
| Max.Input Current from Grid | 15A | 24A | 30A | 36.4A |
| Max.Output Current | 9A | 15A | 18A | 22A |
| Nominal Voltage | 3/N/PE,220/380Vac,230/400Vac | |||
| Grid Voltage Range | 185-276V(P2N) | |||
| PV Input | ||||
| Max.Input Power | 7500Wp | 12000Wp | 15000Wp | 18000Wp |
| Max.Input Voltage | 1000V | |||
| Number of MPPT | 3 | |||
| Max,Input String Per MPPT | 2001/1/1 | |||
| MPPT Voltage Range | 160-960V | |||
| Nominal Voltage | 600V | |||
| Starting Voltage | 160V | |||
| Max.input Current | 20A/20A/20A | |||
| Short-Circuit Current | 24A/24A/24A | |||
| Battery Parameter | ||||
| Battery Type | Lithium-ion/Lead-Acid/Sodium-ion(Optional) | |||
| Number of Battery Input | 2 | |||
| Battery Voltage Range | 33-60V | |||
| Max.Charging/Discharging Current | 52.5A/52.5A | 85A/85A | 105A/105A | 125A/125A |
| Peak Charging/Discharging Current&Duration | 55A/55A-60s | 90A/90A-60S | 110A/110A-60S | 130A/130A-60s |
| Communication Port | RS485/CAN | |||
| Efficiency | ||||
| Max.Efficiency | 98.20% | |||
| Max.Battery Charging/Discharing Efficiency | 96.00% | |||
| General Data | ||||
| Size(W*H*D) | 460mm*650mm*165mm | |||
| Weight | 28kg | |||
| Noise | <45db | |||
| Cooling Method | Smart Cooling | |||
| Protection Grade | lp65 | |||
| Topology | lsolation | |||
| Monitoring | WIF//4G/Bluetooth/RS485 | |||
| Protection | DC Switch:Reverse Polarity Protection(BAT);AC Overvoltage/Overcurrent/Short Circuit Protection;Anti.islanding Protection;Residual Current Monitoring;linsulation Resistance Detection:Surge Protection:DcTypel/ACTypelI;AFCl(Optional);PID(Optional) | |||
| Certification | ||||
| CE-LVD | IEC62109-1&2,IEC62477-1 | |||
| CE-EMC | EN61000-6-1,EN61000-6-2,EN61000-6-3,EN61000-6-4EN 61000-4-16,EN61000-4-18,EN 61000-4-29 | |||
| Grid | VDE-AR-N4105;VDE0126-1-1EN 50549-1;G98,G100;CE10-21;AS/NZS4777.2 NRS 097-2-1; | |||
SolarEawatt Single Phase Hybrid inverter 5-12KW HV
- 200% 0ff-grid OutputOverload
- Sic Technology
- Support OTA Upgrade
- 165mm Ultra-thin
- IP65. Noise <25dB.
- 2 Independent BatteryPorts for Mixture Use of old & New Battery
- Max. PVInput Current 20A
- Independent Generator Port Smart Monitoring
- 3 MPPTS
- AFCI/PID Function
